Inversor Solar Monofásico SANDISOLAR 7KW
Modelo: SD-4870WP-US
This high-efficiency single-phase inverter offering 7000W rated output, 14000W peak power, Suporte para ATÉ 6 parallel units, 99.9% MPPT tracking efficiency, wide battery and PV input compatibility, multiple communication options, and robust safety protections—all in a compact, easy-to-install design certified to UL1741 and FCC standards
-
Key Specs & Visuals
-
-
Destaques
-
- 7000W rated output with 14000W peak power for high-load performance.
- Suportes até 6 units in parallel for system expansion.
- 99.9% MPPT tracking efficiency for maximum solar utilization.
- Wide PV and battery compatibility for flexible system design.
- Multiple communication options enable smart energy management.
- UL1741 and FCC certified for reliable US market operation.
Solicite um orçamento
Baixar o folheto
Vantagens Centrais
High Power Capacity
7000W rated and 14000W peak output.
Parallel Scalability
Suportes até 6 units expansion.
Alta Eficiência
99.9% MPPT tracking efficiency.
Flexible Compatibility
Supports wide PV and battery input range.
Smart Communication
WiFi, Bluetooth, 4G, RS485 supported.
Confiabilidade Certificada
Está em conformidade com os padrões UL1741 e FCC.
Especificação do Produto
| Produção Nominal | 7000Em | Máximo de Potência | 14000Em |
| Rated Output Voltage | Monofásica | Capacidade de Carga do Motor | 4.8HP |
| Potência nominal | 60Hz | Output Voltage Waveform | Onda senoidal pura |
| Number of Units Paralleled | 6 | Rated Battery Voltage | 48V |
| Faixa de Tensão da Bateria | 40–60V | Max PV Charging Current | 120A |
| Tempo de Transferência | 10MS (typical value). Maximum value is 20ms for single unit and 30ms for parallel operation. | Max Mains/Generator Charging Current | 100A |
Ver Documento Completo
Aplicação
This inverter is designed for residential and small commercial solar energy storage systems, providing reliable backup power, solar self-consumption, and energy independence.
